- Modern, dotless side marker light with an integrated reflector.
- Approved for vertical and horizontal mounting.
- ADR-approved version available.
- Supplied pre-terminated with a Superseal connector as standard for fast and simple installation.
- Screws go through the back plate only and not the lamp, maintaining the integrity of the seal.
- Side, front and rear marker light options also available.
- Warranty: 3 Years
- Approvals: ECE R3, R6, R10, R91.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| FastLane | Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | RL198001 | Dotless LED Side Marker Light with Reflector and Direction Indicator, Superseal Connector and Bracket | IP68 | 12/24 | 0.058A @ 12V, 0.063A @ 24V | 250 | SuperSeal | Amber | Amber | N/A | 0.103 | 49(H) X 124(L) X 20(D) |
| RL198002 | Dotless LED Side Marker Light with Reflector and Direction Indicator, Female Superseal Connector and Bracket | IP68 | 12/24 | 0.058A @ 12V, 0.063A @ 24V | 250 | SuperSeal | Amber | Amber | N/A | 0.112 | 49(H) X 124(L) X 20(D) |
Download Product Information
- RL198001 Product Spec Sheet Download
- RL198002 Product Spec Sheet Download
- RL198001 Technical Drawing Download
- RL198002 Technical Drawing Download
- RL198001 R3 Approval Download
- RL198001 R6 Approval Download
- RL198001 R10 Approval Download
- RL198001 R91 Approval Download
To download product materials, please login or register for an account.
