- Available pre-terminated with a range of connectors and pre-set to an R65 flash pattern for super-fast fitment.
- 2.5mm radius edges for additional protection.
- Multiple flash patterns.
- Syncs with other directional units.
- Sleek design and low profile to blend in to your vehicle.
- Excellent light output for maximum visibility.
- Robust aluminium housing and polycarbonate lens.
- Horizontal option also available in the V70 Series.
- Some variants are made to order. Lead times apply.
- Warranty: 3 Years
- Approvals: ECE R10, R65.
The options available for this product are summarised below. For a detailed specification download the Product Technical Specification
| Part Number | Product Name | IP RATING | VOLTAGE (V) DC | CURRENT DRAW (AMPS) | CABLE LENGTH (MM) | CONNECTORS | LIGHT COLOUR | LENS COLOUR | DIAMETER (MM) | WEIGHT (KG) | Dimensions (MM) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| WS0002 | Vertical R65 LED Lighthead - Amber | IP69K | 10-30 | 0.125A @ 12V, 0.076A @ 24V | 200 | None | Amber | Clear | N/A | 0.059 | 11.4(H) X 118(L) X 29(D) |
| WS000201 | Vertical R65 LED Lighthead - Amber with JST Connector, Pre-set Flash Pattern 3 | IP67 | 10-30 | 0.125A @ 12V, 0.076A @ 24V | 235 | JST | Amber | Clear | N/A | 0.065 | 11.4(H) X 118(L) X 29(D) |
| WS000202 | Vertical R65 LED Lighthead - Amber with JST Connector, Pre-set Flash Pattern 4 | IP67 | 10-30 | 0.125A @ 12V, 0.076A @ 24V | 235 | JST | Amber | Clear | N/A | 0.065 | 11.4(H) X 118(L) X 29(D) |
| WS000203 | Vertical R65 LED Lighthead - Amber with SuperSeal Connector, Pre-set Flash Pattern 3 | IP67 | 10-30 | 0.125A @ 12V, 0.076A @ 24V | 240 | Superseal | Amber | Clear | N/A | 0.066 | 11.4(H) X 118(L) X 29(D) |
| WS000204 | Vertical R65 LED Lighthead - Amber with SuperSeal Connector, Pre-set Flash Pattern 4 | IP67 | 10-30 | 0.125A @ 12V, 0.076A @ 24V | 240 | Superseal | Amber | Clear | N/A | 0.066 | 11.4(H) X 118(L) X 29(D) |
Download Product Information
- WS0002 Product Spec Sheet Download
- WS000201 Product Spec Sheet Download
- WS000202 Product Spec Sheet Download
- WS000203 Product Spec Sheet Download
- WS000204 Product Spec Sheet Download
- WS0002 Technical Drawing Download
- WS000201 Technical Drawing Download
- WS000202 Technical Drawing Download
- WS000203 Technical Drawing Download
- WS000204 Technical Drawing Download
- WS0002 R10 Approval Download
- WS0002 R65 Approval Download
To download product materials, please login or register for an account.
