RL100 Series Square LED Rear Light - Tail / Fog

PART NO: RL100TF

Product options
  • Product Overview:
    • Unique homogeneous tail design.
    • Surface mount.
    • Slimline profile.
    • Dual voltage.
    • Stop / tail / indicator and tail / reverse options available in the same series.
  • Warranty: 3 Years
  • Approvals: ECE R7, R10, R38.
Contact Us

The options available for this product are summarised below. For a detailed specification download the Product Technical Specification.

TITLE 100mm Square LED Rear Light - Tail / Fog
PART NUMBER RL100TF
IP RATING IP67
VOLTAGE (V) DC 10-30
CURRENT DRAW (AMPS) Tail: 0.23A @ 12V, 0.115A @ 24V, Fog: 0.275A @ 12V, 0.1375A @24V
CABLE LENGTH (MM) 250
CONNECTORS None
LIGHT COLOUR Red
LENS COLOUR Red
DIAMETER (MM) N/A
LENGTH (MM) 100
HEIGHT (MM) 100
DEPTH (MM) 28
WEIGHT (KG) 0.159
